Ion Power Basic 12 V 100Ah 1280 Wh

$669.94

Descriptions

The WP-Ion Power Plus, is a Lithium Iron Phosphate rechargeable battery with a rated capacity of 160 Ah or 210 Ah. The unique combination of state-of-the art technology and smart software makes this lithium battery a robust, safe and easy to use energy storage solution.

Compared to conventional lead-acid batteries, the WP-Ion Power Plus lithium batteries offers an enormous weight and space saving. Efficient and with extremely high performance.

  • Traction battery (frequent charge/discharges)
  • Lithium Iron Phosphate (LiFePO4): safe lithium technology
  • Integrated BMS (Battery-Management system);
  • External interruption device needed
  • Glass fiber reinforced plastic (GFRP) casing,
  • Aluminum / PE sandwich side panels
  • Terminals for 2 x M8 Bolts
  • Integrated fuse, 32V / 500A
  • Wired communication interface: CAN open
  • Battery monitoring / history storage
  • Adaptive cell balancing
  • Configurable in serial or parallel connection- output for bi-stable relay / latching relay

Specifications

ARTICLE NUMBER
40291202

Ion Power Basic 12 V – 100 Ah

TECHNICAL SPECIFICATIONS
Dimensions (LxWxH) in

12 x 6 x 8

Nominal voltage (V)

12.8 V

Pulsed discharge current (10 sec)

120 A

Usable battery capacity at 20˚C

100 Ah 1280 Wh

Temperature range (charging)

0°C to 45°C

Temperature range (discharging)

-20°C to + 60°C

Temperature range (storage)

0°C to + 40°C
