High quality 12 V Lithium Iron Phosphate (LiFePO4) cells are the basis for WhisperPower’s new lithium storage systems. The new lithium Power Plus Battery Racks are a sustainable and highly energy dense solution to store electrical energy for use “on demand”. Due to the specific characteristics of the Whis- perPower LFP ferro lithium batteries, the battery pack(s) can be charged and discharged at high amperes.
The added value of WhisperPower
All Lithium battery solutions can be supplied just “as a bat- tery”. However, we offer our customers a total solution that eliminates the risk of the user’s battery not being charged, discharged or monitored properly. The system approach goes beyond simply supplying a WhisperPower battery charger or combination inverter/charger. If required, we can supply a complete diesel fuel based fast charge system in combination with the Lithium Power Plus rack with integrated BMS, DC bus bar (s) distribution including fuses and an advanced monitor- ing system that monitors the behavior of the cells inside the battery down to the cell level: WhisperCare.
Sustainable and cleaner for the user
Further electrification to replace or supplement fossil power solutions reduces the carbon footprint on a substantial basis. In addition, large cost savings can be achieved because the fossil power system can be used much more efficiently.
A higher upfront investment is recouped within a short time.
Lithium Power Plus modular battery rack system
Added Value Services from WhisperPower
|40290219||Ion Power Plus 12 V – 320 Ah|
|Battery NR code||IFpP/41/173/205|
|Dimensions (LxWxH) mm||227 x 417 x 314|
|Weight||33 kg / 72.7 lbs|
|Nominal voltage||12.8 V|
|Maximum voltage||15.4 VDC|
|End charge voltage||14.3 VDC|
|Max charge current 100/c||320 A|
|Max float charge current||100 A|
|Minimum battery voltage||8 VDC|
|Minimum float charge||10 VDC|
|Max discharge current||500 A|
|Pulsed discharge current (10 sec)||800 A|
|Pulsed discharge current (60 sec)||600 A|
|Usable battery capacity at – 20 ̊C||130 Ah / 1716 Wh|
|Usable capacity / in comparison to lead acid battery||600 Ah|
|Charge method||Constant voltage|
|Temperature range (charging)||0°C to 45°C|
|Temperature range (discharging)||-20°C to +60°C|
|Temperature range (storage)||-20°C to +60°C|
|Certifications||CE, FCC, UN 38.3, UN ECE R10.06, UL 1642 (Celis)|
|Shipping Classification||UN 3480|
