When leaving the marina and heading for the ocean, you are getting fully dependent on your boat electrical system. With Whisper- Power, you are secured electricity is guided into the appropriate conduits which prevents dangerous situations. The WhisperPower DC distribution program offers high quality components ensuring a safe and enjoyable trip.
DIMENSIONS & WEIGHT | |
Weight (Kg) | 0.8 |
Enclosure width | 95.25 mm |
Enclosure height | 138.94 mm |
Enclouser depth | 51.56 mm |
GENERAL | |
Ambient operation temperature | -20°C … +40°C |
Storage temperature | -25oC … +85oC |
Operating humidity | 95%, non condens |
Live current switching | 100.000 cyles |
MECHANICAL | |
Connections terminal stud | M10 (3/8”-.16) |
Connections stud lenght | 23 mm |
Maximum terminal Stud Torque | 15.5 NM (140 in-lb) |
Terminal material | tin-plated copper |
Drilling mounting centers | 114.3mm * 76.20mm |
Mounting screws | 4 mm |
Ingress Protection Class | IP66 |
Enclouser Colour | RAL9011 Graphite Black |
Calbe clearance | 28.4 mm (1.12”) |
Ignition Protection | SA J1171 |
Markings | CE, Iso 8846 |
INPUT | |
Battery input | 2 |
Switch Positions | 2 |
Manual overide | Locked off/on |
I 10 Cranking rating 10 sec | 2500A |
I 60 Cranking rating 1 min | 1100A |
I 300 Cintermittent rating 5 min | 700A |
I C continue rating | 500A |
Vmno Voltage maxium Operation | 32V DC |
Control Circuit Voltage | 10.1..16.5VDC |
Operation current continuous | < 40mA |
Operation current when charging | <7A |
Remote Control switch when charging | 100mA |
Automatically combines battery banks when sensed voltage levels are: | Above 13.5 for 30 sec. Above 13.0 for 90 sec. |
Automatically isolates battery banks when sensed voltage levels are: | Below 9.6V (undervoltage lockout) Below 12.35V for 10 sec. Below 12.75V for 30 sec. Above 16.2V (undervoltage lockout) |
